The strongest wet room shower tray on the market. It supports an incredible 100 stone (635 kg) with NO under-boarding required, simply fix it directly to the joists. Perfect for both tiled and vinyl floor finishes.

SPECIFICATION	SUITABLE FOR	NOT SUITABLE FOR
1800 x 820 x 24mm	Wood or concrete subfloor	Micro Cement
Square drain style	Tiled floor finish	Â
Supports up to 100st / 653kg	Vinyl floor finish
Tiled, Vinyl & Pumped Drain Options	Underfloor heating	Â
Under support NOT required	Wet rooms	Â
Can be trimmed	Level access
Fit direct to joists	Use with wheelchairs
Lifetime guarantee*	Fitting direct to joists

The ShowerDec from Contour is an incredibly strong wet room / walk in shower former tray that is suitable for tiled or vinyl floor finish, and can be installed in wooden or concrete sub floors. Designed for level access Â wet rooms and shower areas, the ShowerDec is suitable for use with wheelchairs and similar devices, with out the need for under supporting.

The ShowerDec is tested to withstand 100 stone / 635Kg across the entire surface area to simulate a standing person. At just 24mm thick the ShowerDec is suitable for installing direct onto floor joists, the remaining floor should then be boarded to the same level.

ShowerDec floor formers are available in 12 size options and can be further cut to size using a circular saw or jigsaw. The ShowerDec features offset drain positions designed to avoid joists, trays are not handed. A standard vinyl waste and stainless steel tile and vinyl waste options are available, in addition Â to a pumped outlet (pump available separately

Waste Options:

The Contour Shower Dec is NOT supplied with a waste as standard. Please specific Â your option when ordering.

CTW01 -Â ABS white VINYL drain:

2 part, 50mm water seal trapped waste for use with a wet room floor former.
Bolts together for easy installation.
Push on cover plate with removable inner cup for cleaning.
Flow rate in excess of 26 litres per minute.
1Â½â€ outlet.
Tested in accordance with EN274-2:2002
Top access, easy to clean.
Manufactured in white ABS, will withstand wheelchair loadings.
100mm deep.

TSG52 - ABS drain body withÂ Stainless steel grate for vinyl (round) or tiled (square) floor (please specify):

Stainless steel option for use with vinyl safety flooring (round grate) or tiled floor (square grate).
2 part, 50mm water seal trapped gully.
Flow rate in excess of 40 litres per minute.
1Â½â€ outlet.
Top access, easy to clean.
Gully manufactured in white ABS, will withstand wheelchair loadings.
100mm deep.

CUW01Â - Outlet for use withÂ shower waste pumpsÂ (does not include pump):

Use with a wet room floor former and flexible vinyl sheet flooring.
To be used in conjunction with a shower waste pump.
Push on cover plate, with 22mm outlet.
Top access, easy to clean.
Manufactured in white ABS, will withstand wheelchair loadings.
Increased outlet length for easier installation.
45mm deep.

LB00104 -Â Stainless Steel PGTF Pumped Gulley Waste for TILED Floors -Â Pump NOT included

22mm depth below tray = 44mm - Low level waste option for unbreachable floors
22mm JG SpeedfitÂ® outlet
Opens for easy cleaning and rodding - Ensuring easy maintenance
Stainless steel plate dimensions = 120x120mm - Provides an easy fitting for ceramic tiles
Stainless steel plate height is adjustable to max of 18mm - Designed to accommodate variants in ceramic tile finishes
Lifetime WarrantyÂ - Provides peace of min

This Product May Be Purchasable VAT Free

If you are purchasing wet room equipment and fittings (trays, grab rails and seats etc) and are registered disabled, or they are for use by a person registered as disabled, you may be eligible for VAT relief on the items.

For full details and eligibility criteria please see the following page:
VAT Relief on Wet Room Purchases

1800 x 820mm
